Once more for good luck this morning and.I can live with this while wrapping up the drop dead deadline today. I ran the Media Advance Calibration about 4 times last night with better results each run.

Softplan 13 manual manual#

Just follow the directions either in the manual or on the display. Once in place with the blue lever down and the canopy closed.you'll wind back up on the Paper menu.for it to read. Once printed and cut, the next procedure is to unload the roll from the platen and insert the new pattern page in the correct layout.adjust the sheet to the side lines scribed into the roll off and paper chamber.

Softplan 13 manual full#

The procedure is found in section 5-9 of the service manual." Which is an easy enough procedure.be certain you've got clearance for multi-excursions around your DJ to load rolls and sheets multiple times as the calibration uses a full page to print out the patterns. If the carriage height is the problem, you'll usually see ghosting in both dimensions (X and Y). I sent Ted Wert a few photos to give them an idea as well as ask about the High Carriage issue as a possibility. I did learn after snapping the damn thing in half.the thin black plastic trailing cable friction clip is there for two purposes.to protect the trailing cable from getting in the way and to break upon removal for $17 each.Wert videos were quite helpful not only in the proper sequence of things to do.but gave me a better idea on positioning rather than a graphic. A $60 fix would be great.and makes more sense than 3 of 4 print heads that suddenly started to print in double. For the price of print heads.I'd just as soon be right on where the money goes. I'll send LPS a note and attachment to see what they have in mind as the cause. Heavy little critter but fired up the first time and went to work which was a boon as I feel more comfortable with a scale drawing than hoping I picked up everything on the monitors. I bought it back when they were relatively new in 2000.or at least the version that I purchased for about $1700. As soon as I clear this job off my "table" I'll spend some time in the fix and maintenance mode on my 500. The manual is a great piece of work.but the videos from Bob Wert were the BEST freebie one could ask for with regards to breaking into the inner workings. I used LPS a number of times when it came to the proper replacement ailing cables, carriage belt, blue handle paper release, etc. Thanks for the tip and the info on Building Options herein the TUTs site that explained the Custom Viz set up for each drawing. I'm getting mighty used to Building Options and Custom Visibilities on each plan. If so.I can rough draft what I need for any changes and then drag the full set up to the printers.

Softplan 13 manual pdf#

I've dropped a pdf for a page on my thumb drive and am going to take a one of today's prints with me to show what I've got and ask them if they'd print this one page just to make sure that it's the printer.

(I just started using Build Options full time on this job) and the confusion reigned a bit over the past few weeks.but if you really need to learn something, do it with the clock ticking down.
